Building the query "Download record counts of Peron's tree frog since 2018 in New South Wales by FrogID"
Overview
Teaching: 20 min
Exercises: 15 minQuestions
How do I build a query using galah-python?
How do I look up information?
How do I filter data?
Objectives
Look up a species and get the number of records the Atlas has for it
Identify filters to use for your data, their possible values, and add it to your galah query
Filter data using the above two objectives
Note: your number of records may be higher than the numbers listed for the rest of the lesson if you’re using this later than September 2023. As long as it is greater than or equal to the above number, the query worked.
What does Peron’s Tree Frog look like?
Indiaianson CC BY NC
Jeannie CC BY NC
Step one: looking up Peron’s Tree Frog
Download record counts of Peron's tree frog since 2018 in New South Wales by FrogID
As the first part of building this query, we need to look up the scientific name of Peron’s tree frog. A quick Google search reveals that the scientific name is Litoria peronii.
Check correct scientific name
To check that Litoria peronii is the scientific name for Peron’s tree frog in the ALA, run the query
galah.search_taxa("litoria peronii")
scientificName scientificNameAuthorship ... species vernacularName issues
0 Litoria peronii (Tschudi, 1838) ... Litoria peronii Peron's Tree Frog noIssue
From the output above, you can see that the vernacular name, or the common name of Litoria peronii, is “Peron’s Tree Frog”, so we have confirmed this is the species name we are looking for in the Atlas.
If you misspell your query, or search for something that is not in our database, you will get an empty dataframe.
galah.search_taxa("incorrect taxa")
Empty DataFrame
Columns: []
Index: []
If you want to search for multiple taxa at once, it is possible to do so. Here, we will enter the scientific name of Peron’s Tree Frog, as well as the Common Froglet (Crinia signifera) and the Cane Toad (Rhinella marina).
galah.search_taxa(taxa=["litoria peronii","Crinia signifera", "Rhinella marina"])
scientificName scientificNameAuthorship rank ... genus species vernacularName issues
0 Litoria peronii (Tschudi, 1838) species ... Litoria Litoria peronii Peron's Tree Frog noIssue
1 Crinia signifera Girard, 1853 species ... Crinia Crinia signifera Common Froglet noIssue
2 Rhinella marina (Linnaeus, 1758) species ... Rhinella Rhinella marina Cane Toad noIssue
Now, we can get the raw record counts of Peron’s Tree Frog:
galah.atlas_counts(
taxa="litoria peronii"
)
totalRecords
0 86105
Filter our data by year
Download record counts of Peron's Tree Frog since 2018 in New South Wales by FrogID
Now, we want to get records from 2018 to now. To figure out what fields we can narrow our query by, we will use the show_all() function.
galah.show_all(
fields=True
)
id description type link
0 _nest_parent_ NaN field NaN
1 _nest_path_ NaN field NaN
2 _root_ NaN field NaN
3 abcdTypeStatus ABCD field in use by herbaria field NaN
4 acceptedNameUsage http://rs.tdwg.org/dwc/terms/acceptedNameUsage field NaN
.. ... ... ... ...
749 multimediaLicence Media filter field media
750 images Media filter field media
751 videos Media filter field media
752 sounds Media filter field media
753 qid Reference to pre-generated query other
Since there are over 700 possible fields to narrow our search by, we know that part of the field would be “year”. Thus, we can use the search_values() function to search for values that contain the word “year”.
galah.search_all(
fields="year",column_name="id"
)
id description type link
0 year The year in which an occurrence was observed. ... field https://github.com/AtlasOfLivingAustralia/ala-...
1 raw_year NaN field NaN
2 endDayOfYear http://rs.tdwg.org/dwc/terms/endDayOfYear field NaN
3 occurrenceYear Year ranges for a search. Calculated based on ... field NaN
4 startDayOfYear http://rs.tdwg.org/dwc/terms/startDayOfYear field NaN
5 raw_endDayOfYear NaN field NaN
6 raw_startDayOfYear NaN field NaN
7 namePublishedInYear http://rs.tdwg.org/dwc/terms/namePublishedInYear field NaN
As we can see by the description of the “year” field, this specifies the year in which an occurrence was observed, which is what we want. Now, we add the filter to the above query:
galah.atlas_counts(
taxa="litoria peronii",
filters="year>=2018"
)
totalRecords
0 61490
As this is less than the 88184 records that were shown above, we can see we have already filtered the data.
Adding other filters: Australian States
Download record counts of Peron's Tree Frog since 2018 in New South Wales by FrogID
Now, we will practice adding other possible filters for our query. First, we will add the specification that we want the counts only in the state of New South Wales.
galah.search_all(
fields="Australian States"
)
id description type link
0 cl22 Australian States and Territories Australian S... layers
1 cl2013 ASGS Australian States and Territories Austral... layers
The filter name that we will use is cl22. cl22 is named as follows:
cl= Contextual Layer (something that’s meant to put occurrences into context)22= it was the 22nd layer to be added to the ALA’s spatial data layers
year above was relatively self-explanatory, in that the filter was looking for four digits representing a year. However, what value we should set cl22 as is not obvious. To learn what values are possible for the field cl22, we will use the the show_values() function of galah-python as follows:
galah.show_values(
field="cl22"
)
field category
0 cl22 New South Wales
1 cl22 Victoria
2 cl22 Queensland
3 cl22 South Australia
4 cl22 Western Australia
5 cl22 Northern Territory
6 cl22 Tasmania
7 cl22 Australian Capital Territory
8 cl22 Unknown1
9 cl22 Coral Sea Islands
10 cl22 Ashmore and Cartier Islands
Here, we get all possible values for cl22, and can see that New South Wales is the string that we need to set as cl22’s value.
Now, we can apply that filter to the query as follows:
galah.atlas_counts(
taxa="litoria peronii",
filters=["year>=2018",
"cl22=New South Wales"]
)
totalRecords
0 47714
Adding other filters: Data Resources
Download record counts of Peron's Tree Frog since 2018 in New South Wales by FrogID
To get the last part of the query, will be searching for a specific data provider. In the ALA, they are known as “data resources”. To search for the list of data resources, or data providers, we will use the phrase “dataResource” to search for values.
galah.search_all(
fields="data",
column_name="id"
)
id description type link
0 inDataset NaN field NaN
1 datasetID http://rs.tdwg.org/dwc/terms/datasetID field NaN
2 dataHubUid The Atlas thematic groups for this record. field NaN
3 datasetName The name of the dataset for this record. Typic... field NaN
4 dataHubName NaN field NaN
5 dataProviderUid The Atlas ID for the data resource field NaN
6 dataResourceUid A list (concatenated and separated) of prepara... field NaN
7 raw_datasetTitle NaN field NaN
8 text_datasetName NaN field NaN
9 dataProviderName The data provider for this record field NaN
10 dataResourceName The data resource that supplies the record. Th... field NaN
11 raw_dataProviderUid NaN field NaN
12 raw_dataResourceUid NaN field NaN
13 dataGeneralizations http://rs.tdwg.org/dwc/terms/dataGeneralizations field NaN
14 raw_dataProviderName NaN field NaN
15 raw_dataResourceName NaN field NaN
16 raw_dataGeneralizations NaN field NaN
For our query, we will be choosing dataResourceName. This is because FrogID is a data resource for the ALA, and searching under dataResourceName rather than dataResourceUid will yield better results in this case.
to show values, type
galah.show_values(
field="dataResourceName"
)
field category
0 dataResourceName eBird Australia
1 dataResourceName NSW BioNet Atlas
2 dataResourceName BirdLife Australia, Birdata
3 dataResourceName Victorian Biodiversity Atlas
4 dataResourceName iNaturalist Australia
... ... ...
1090 dataResourceName Scotland Island
1091 dataResourceName The second confirmed record and a significant ...
1092 dataResourceName Tidbinbilla Nature Recording System
1093 dataResourceName Tweed Council Koala Count
1094 dataResourceName Warrumbungle Koala Project
Unlike for Australian States, in which there are 10 possible values, there are over 1000 data resources the ALA gets its data from. To search for the FrogID value in these data resources, we can use the function search_values() to search for the specific value we need.
galah.search_values(
field="dataResourceName",
value="frogid"
)
field category
0 dataResourceName FrogID
Now, we can add the final filter to our query.
galah.atlas_counts(
taxa="litoria peronii",
filters=["year>=2018",
"cl22=New South Wales",
"dataResourceName=FrogID"]
)
totalRecords
0 39840
Key Points
When looking up taxa, check you have the right one by checking the vernacular name matches the scientific name
The atlas has many ways to filter data - use
galah-python’s helper functions to choose the right filter
galah-pythoncan be used in many ways to get species data you want
